| Type | : Formed Type |
| Feature | : High strength thanks to the forms on it |
| Code | : EU |
| Advantages | : Cost |
| Thickness | : 0,60 – 1,20 mm |
| Width | : 100-600 mm |
CoatIng Types
Technıcal Tables
| # | Product Code | Product Description | T (mm) | W (mm) | H (mm) | Weight (kg/m) |
| 1 | EU-10040-060 | Reinforced Type Cable Trays | 0.6 | 100 | 40 | 0.989 |
| 2 | EU-10040-080 | Reinforced Type Cable Trays | 0.8 | 100 | 40 | 1.265 |
| 3 | EU-10040-100 | Reinforced Type Cable Trays | 1.0 | 100 | 40 | 1.540 |
| 4 | EU-10040-120 | Reinforced Type Cable Trays | 1.2 | 100 | 40 | 1.829 |
| 5 | EU-20040-060 | Reinforced Type Cable Trays | 0.6 | 200 | 40 | 1.498 |
| 6 | EU-20040-080 | Reinforced Type Cable Trays | 0.8 | 200 | 40 | 1.915 |
| 7 | EU-20040-100 | Reinforced Type Cable Trays | 1.0 | 200 | 40 | 2.333 |
| 8 | EU-20040-120 | Reinforced Type Cable Trays | 1.2 | 200 | 40 | 2.770 |
| 9 | EU-30040-060 | Reinforced Type Cable Trays | 0.6 | 300 | 40 | 1.981 |
| 10 | EU-30040-080 | Reinforced Type Cable Trays | 0.8 | 300 | 40 | 2.533 |
| 11 | EU-30040-100 | Reinforced Type Cable Trays | 1.0 | 300 | 40 | 3.085 |
| 12 | EU-30040-120 | Reinforced Type Cable Trays | 1.2 | 300 | 40 | 3.662 |
| 13 | EU-40040-060 | Reinforced Type Cable Trays | 0.6 | 400 | 40 | 2.491 |
| 14 | EU-40040-080 | Reinforced Type Cable Trays | 0.8 | 400 | 40 | 3.185 |
| 15 | EU-40040-100 | Reinforced Type Cable Trays | 1.0 | 400 | 40 | 3.879 |
| 16 | EU-40040-120 | Reinforced Type Cable Trays | 1.2 | 400 | 40 | 4.604 |
| 17 | EU-50040-060 | Reinforced Type Cable Trays | 0.6 | 500 | 40 | 2.975 |
| 18 | EU-50040-080 | Reinforced Type Cable Trays | 0.8 | 500 | 40 | 3.804 |
| 19 | EU-50040-100 | Reinforced Type Cable Trays | 1.0 | 500 | 40 | 4.632 |
| 20 | EU-50040-120 | Reinforced Type Cable Trays | 1.2 | 500 | 40 | 5.499 |
| 21 | EU-60040-060 | Reinforced Type Cable Trays | 0.6 | 600 | 40 | 3.482 |
| 22 | EU-60040-080 | Reinforced Type Cable Trays | 0.8 | 600 | 40 | 4.452 |
| 23 | EU-60040-100 | Reinforced Type Cable Trays | 1.0 | 600 | 40 | 5.422 |
| 24 | EU-60040-120 | Reinforced Type Cable Trays | 1.2 | 600 | 40 | 6.436 |
| # | Product Code | Product Description | T (mm) | W (mm) | H (mm) | Weight (kg/m) |
| 1 | EU-10050-060 | Reinforced Type Cable Trays | 0.6 | 100 | 50 | 1.102 |
| 2 | EU-10050-080 | Reinforced Type Cable Trays | 0.8 | 100 | 50 | 1.409 |
| 3 | EU-10050-100 | Reinforced Type Cable Trays | 1.0 | 100 | 50 | 1.716 |
| 4 | EU-10050-120 | Reinforced Type Cable Trays | 1.2 | 100 | 50 | 2.037 |
| 5 | EU-20050-060 | Reinforced Type Cable Trays | 0.6 | 200 | 50 | 1.610 |
| 6 | EU-20050-080 | Reinforced Type Cable Trays | 0.8 | 200 | 50 | 2.060 |
| 7 | EU-20050-100 | Reinforced Type Cable Trays | 1.0 | 200 | 50 | 2.509 |
| 8 | EU-20050-120 | Reinforced Type Cable Trays | 1.2 | 200 | 50 | 2.979 |
| 9 | EU-30050-060 | Reinforced Type Cable Trays | 0.6 | 300 | 50 | 2.094 |
| 10 | EU-30050-080 | Reinforced Type Cable Trays | 0.8 | 300 | 50 | 2.677 |
| 11 | EU-30050-100 | Reinforced Type Cable Trays | 1.0 | 300 | 50 | 3.260 |
| 12 | EU-30050-120 | Reinforced Type Cable Trays | 1.2 | 300 | 50 | 3.870 |
| 13 | EU-40050-060 | Reinforced Type Cable Trays | 0.6 | 400 | 50 | 2.604 |
| 14 | EU-40050-080 | Reinforced Type Cable Trays | 0.8 | 400 | 50 | 3.329 |
| 15 | EU-40050-100 | Reinforced Type Cable Trays | 1.0 | 400 | 50 | 4.054 |
| 16 | EU-40050-120 | Reinforced Type Cable Trays | 1.2 | 400 | 50 | 4.813 |
| 17 | EU-50050-060 | Reinforced Type Cable Trays | 0.6 | 500 | 50 | 3.088 |
| 18 | EU-50050-080 | Reinforced Type Cable Trays | 0.8 | 500 | 50 | 3.948 |
| 19 | EU-50050-100 | Reinforced Type Cable Trays | 1.0 | 500 | 50 | 4.808 |
| 20 | EU-50050-120 | Reinforced Type Cable Trays | 1.2 | 500 | 50 | 5.707 |
| 21 | EU-60050-060 | Reinforced Type Cable Trays | 0.6 | 600 | 50 | 3.595 |
| 22 | EU-60050-080 | Reinforced Type Cable Trays | 0.8 | 600 | 50 | 4.596 |
| 23 | EU-60050-100 | Reinforced Type Cable Trays | 1.0 | 600 | 50 | 5.597 |
| 24 | EU-60050-120 | Reinforced Type Cable Trays | 1.2 | 600 | 50 | 6.644 |
| # | Product Code | Product Description | T (mm) | W (mm) | H (mm) | Weight (kg/m) |
| 1 | EU-10060-060 | Reinforced Type Cable Trays | 0.6 | 100 | 60 | 1.214 |
| 2 | EU-10060-080 | Reinforced Type Cable Trays | 0.8 | 100 | 60 | 1.553 |
| 3 | EU-10060-100 | Reinforced Type Cable Trays | 1.0 | 100 | 60 | 1.892 |
| 4 | EU-10060-120 | Reinforced Type Cable Trays | 1.2 | 100 | 60 | 2.246 |
| 5 | EU-20060-060 | Reinforced Type Cable Trays | 0.6 | 200 | 60 | 1.723 |
| 6 | EU-20060-080 | Reinforced Type Cable Trays | 0.8 | 200 | 60 | 2.204 |
| 7 | EU-20060-100 | Reinforced Type Cable Trays | 1.0 | 200 | 60 | 2.684 |
| 8 | EU-20060-120 | Reinforced Type Cable Trays | 1.2 | 200 | 60 | 3.187 |
| 9 | EU-30060-060 | Reinforced Type Cable Trays | 0.6 | 300 | 60 | 2.207 |
| 10 | EU-30060-080 | Reinforced Type Cable Trays | 0.8 | 300 | 60 | 2.821 |
| 11 | EU-30060-100 | Reinforced Type Cable Trays | 1.0 | 300 | 60 | 3.436 |
| 12 | EU-30060-120 | Reinforced Type Cable Trays | 1.2 | 300 | 60 | 4.079 |
| 13 | EU-40060-060 | Reinforced Type Cable Trays | 0.6 | 400 | 60 | 2.717 |
| 14 | EU-40060-080 | Reinforced Type Cable Trays | 0.8 | 400 | 60 | 3.473 |
| 15 | EU-40060-100 | Reinforced Type Cable Trays | 1.0 | 400 | 60 | 4.230 |
| 16 | EU-40060-120 | Reinforced Type Cable Trays | 1.2 | 400 | 60 | 5.021 |
| 17 | EU-50060-060 | Reinforced Type Cable Trays | 0.6 | 500 | 60 | 3.200 |
| 18 | EU-50060-080 | Reinforced Type Cable Trays | 0.8 | 500 | 60 | 4.092 |
| 19 | EU-50060-100 | Reinforced Type Cable Trays | 1.0 | 500 | 60 | 4.983 |
| 20 | EU-50060-120 | Reinforced Type Cable Trays | 1.2 | 500 | 60 | 5.916 |
| 21 | EU-60060-060 | Reinforced Type Cable Trays | 0.6 | 600 | 60 | 3.708 |
| 22 | EU-60060-080 | Reinforced Type Cable Trays | 0.8 | 600 | 60 | 4.740 |
| 23 | EU-60060-100 | Reinforced Type Cable Trays | 1.0 | 600 | 60 | 5.773 |
| 24 | EU-60060-120 | Reinforced Type Cable Trays | 1.2 | 600 | 60 | 6.853 |
| # | Product Code | Product Description | T (mm) | W (mm) | H (mm) | Weight (kg/m) |
| 1 | EU-10075-060 | Reinforced Type Cable Trays | 0.6 | 100 | 75 | 1.384 |
| 2 | EU-10075-080 | Reinforced Type Cable Trays | 0.8 | 100 | 75 | 1.769 |
| 3 | EU-10075-100 | Reinforced Type Cable Trays | 1.0 | 100 | 75 | 2.155 |
| 4 | EU-10075-120 | Reinforced Type Cable Trays | 1.2 | 100 | 75 | 2.558 |
| 5 | EU-20075-060 | Reinforced Type Cable Trays | 0.6 | 200 | 75 | 1.892 |
| 6 | EU-20075-080 | Reinforced Type Cable Trays | 0.8 | 200 | 75 | 2.420 |
| 7 | EU-20075-100 | Reinforced Type Cable Trays | 1.0 | 200 | 75 | 2.948 |
| 8 | EU-20075-120 | Reinforced Type Cable Trays | 1.2 | 200 | 75 | 3.500 |
| 9 | EU-30075-060 | Reinforced Type Cable Trays | 0.6 | 300 | 75 | 2.376 |
| 10 | EU-30075-080 | Reinforced Type Cable Trays | 0.8 | 300 | 75 | 3.038 |
| 11 | EU-30075-100 | Reinforced Type Cable Trays | 1.0 | 300 | 75 | 3.699 |
| 12 | EU-30075-120 | Reinforced Type Cable Trays | 1.2 | 300 | 75 | 4.391 |
| 13 | EU-40075-060 | Reinforced Type Cable Trays | 0.6 | 400 | 75 | 2.886 |
| 14 | EU-40075-080 | Reinforced Type Cable Trays | 0.8 | 400 | 75 | 3.689 |
| 15 | EU-40075-100 | Reinforced Type Cable Trays | 1.0 | 400 | 75 | 4.493 |
| 16 | EU-40075-120 | Reinforced Type Cable Trays | 1.2 | 400 | 75 | 5.334 |
| 17 | EU-50075-060 | Reinforced Type Cable Trays | 0.6 | 500 | 75 | 3.369 |
| 18 | EU-50075-080 | Reinforced Type Cable Trays | 0.8 | 500 | 75 | 4.308 |
| 19 | EU-50075-100 | Reinforced Type Cable Trays | 1.0 | 500 | 75 | 5.247 |
| 20 | EU-50075-120 | Reinforced Type Cable Trays | 1.2 | 500 | 75 | 6.228 |
| 21 | EU-60075-060 | Reinforced Type Cable Trays | 0.6 | 600 | 75 | 3.877 |
| 22 | EU-60075-080 | Reinforced Type Cable Trays | 0.8 | 600 | 75 | 4.957 |
| 23 | EU-60075-100 | Reinforced Type Cable Trays | 1.0 | 600 | 75 | 6.036 |
| 24 | EU-60075-120 | Reinforced Type Cable Trays | 1.2 | 600 | 75 | 7.165 |
| # | Product Code | Product Description | T (mm) | W (mm) | H (mm) | Weight (kg/m) |
| 1 | EH-100100-120 | Reinforced Type Cable Trays | 1.2 | 100 | 100 | 2.852 |
| 2 | EH-100100-150 | Reinforced Type Cable Trays | 1.5 | 100 | 100 | 3.497 |
| 3 | EH-100100-200 | Reinforced Type Cable Trays | 2.0 | 100 | 100 | 4.556 |
| 4 | EH-150100-120 | Reinforced Type Cable Trays | 1.2 | 150 | 100 | 3.282 |
| 5 | EH-150100-150 | Reinforced Type Cable Trays | 1.5 | 150 | 100 | 4.019 |
| 6 | EH-150100-200 | Reinforced Type Cable Trays | 2.0 | 150 | 100 | 5.213 |
| 7 | EH-200100-120 | Reinforced Type Cable Trays | 1.2 | 200 | 100 | 3.683 |
| 8 | EH-200100-150 | Reinforced Type Cable Trays | 1.5 | 200 | 100 | 4.516 |
| 9 | EH-200100-200 | Reinforced Type Cable Trays | 2.0 | 200 | 100 | 5.894 |
| 10 | EH-250100-120 | Reinforced Type Cable Trays | 1.2 | 250 | 100 | 3.937 |
| 11 | EH-250100-150 | Reinforced Type Cable Trays | 1.5 | 250 | 100 | 4.827 |
| 12 | EH-250100-200 | Reinforced Type Cable Trays | 2.0 | 250 | 100 | 6.303 |
| 13 | EH-300100-120 | Reinforced Type Cable Trays | 1.2 | 300 | 100 | 4.593 |
| 14 | EH-300100-150 | Reinforced Type Cable Trays | 1.5 | 300 | 100 | 5.632 |
| 15 | EH-300100-200 | Reinforced Type Cable Trays | 2.0 | 300 | 100 | 7.359 |
| 16 | EH-400100-120 | Reinforced Type Cable Trays | 1.2 | 400 | 100 | 5.530 |
| 17 | EH-400100-150 | Reinforced Type Cable Trays | 1.5 | 400 | 100 | 6.780 |
| 18 | EH-400100-200 | Reinforced Type Cable Trays | 2.0 | 400 | 100 | 8.867 |
| 19 | EH-500100-120 | Reinforced Type Cable Trays | 1.2 | 500 | 100 | 6.335 |
| 20 | EH-500100-150 | Reinforced Type Cable Trays | 1.5 | 500 | 100 | 7.767 |
| 21 | EH-500100-200 | Reinforced Type Cable Trays | 2.0 | 500 | 100 | 10.163 |
| 22 | EH-600100-120 | Reinforced Type Cable Trays | 1.2 | 600 | 100 | 7.272 |
| 23 | EH-600100-150 | Reinforced Type Cable Trays | 1.5 | 600 | 100 | 8.915 |
| 24 | EH-600100-200 | Reinforced Type Cable Trays | 2.0 | 600 | 100 | 11.670 |
*Hot Dip Galvanizing (TS EN ISO 1461)
- Material weights are approximate values, may vary ± 10%.
- The table is based on the weights of products coated with hot dip galvanizing.
- Standard lengths are 2500 mm and 3000 mm.
- For detailed information and special size orders, please contact your customer representative.
